Cisco WS-C3560E-24PD-E User Manual

2-30
Catalyst 3560 Switch Command Reference
78-16405-05
Chapter 2 Catalyst 3560 Switch Cisco IOS Commands
channel-group
channel-group
Use the channel-group interface configuration command to assign an Ethernet port to an EtherChannel
group, to enable an EtherChannel mode, or both. Use the no form of this command to remove an Ethernet
port from an EtherChannel group.
channel-group channel-group-number mode {active | {auto [non-silent]} | {desirable
[non-silent]} | on | passive}
no channel-group
PAgP modes:
channel-group channel-group-number mode {{auto [non-silent]} | {desirable [non-silent}}
LACP modes:
channel-group channel-group-number mode {active | passive}
On mode:
channel-group channel-group-number mode on
Syntax Description channel-group-number Specify the channel group number. The range is 1 to 48.
mode Specify the EtherChannel mode.
active Unconditionally enable Link Aggregation Control Protocol (LACP).
Active mode places a port into a negotiating state in which the port initiates
negotiations with other ports by sending LACP packets. A channel is
formed with another port group in either the active or passive mode.
auto Enable the Port Aggregation Protocol (PAgP) only if a PAgP device is
detected.
Auto mode places a port into a passive negotiating state in which the port
responds to PAgP packets it receives but does not start PAgP packet
negotiation. A channel is formed only with another port group in desirable
mode. When auto is enabled, silent operation is the default.
desirable Unconditionally enable PAgP.
Desirable mode places a port into an active negotiating state in which the
port starts negotiations with other ports by sending PAgP packets. An
EtherChannel is formed with another port group that is in the desirable or
auto mode. When desirable is enabled, silent operation is the default.
non-silent (Optional) Use in PAgP mode with the auto or desirable keyword when
traffic is expected from the other device.
on Enable on mode.
In on mode, a usable EtherChannel exists only when both connected port
groups are in the on mode.
passive Enable LACP only if a LACP device is detected.
Passive mode places a port into a negotiating state in which the port
responds to received LACP packets but does not initiate LACP packet
negotiation. A channel is formed only with another port group in active
mode.
