Citizen CL-E321 User Manual

32
——
7.
Slide the head balance adjustment slider located near the thermal head along the media
size scale (inch) so that the position of the notch in the slider matches the media width.
2 ” 3 ” 4 ”
4.65 ”
1 ”
Head balance
adjustment slider
media
size scale
Thermal
printhead
CAUTION
 Adjust the head pressure horizontal balance carefully so as not to damage the thermal head.
Damaged thermal heads will result in poor printing, paper jams, and malfunction.
 If using media in thermal-transfer printing with a width of 2 inches or less, we recommend set-
ting the head balance adjustment slider to 2.5” (between 2” and 3”).
8. Close the top cover.
CAUTION
Press the push marks on left and right sides at the top of the top cover and ensure that the top
cover hooks on each side lock securely.
If the top cover is not securely locked, this may cause print errors, paper jams, and malfunction.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
