Citizen CL-E321 User Manual

45
——
11. Close the top cover.
CAUTION
 When closing the top cover, push in the parts indicated by arrows with both hands until you
hear the clicking sound of the left and right hooks engaging.
If the hooks are not sufciently engaged, the print quality may be affected. If wrinkles occur in
the ribbon, press the Feeds key until there are no wrinkles.
If there are still wrinkles in the ribbon, perform the procedure described in “Adjusting the Left/
Right Balance of the Ribbon”.
 Use ribbon that has the ink surface on the outer side. Ribbon that has the ink surface on the
inner side cannot be used.
If ribbon that has the ink surface on the inner side is used, the print quality may deteriorate.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
