Citizen CL-E321 User Manual

60
——
Home menu Sub menu Default Congurable range Notes
Interface - 1
*1
RS-232C Baud
Rate
9600 115200
57600
38400
19200
9600
4800
2400
Sets the baud rate of the serial
interface
RS-232C Parity None None
Odd
Even
Sets the communication parity of
the serial interface
RS-232C
Length
8 bits 8 bits
7 bits
Sets the data length for the serial
interface
RS-232C
Stop bit
1 bit 1 bit
2 bits
Sets the stop bits for the serial
interface
RS-232C X-ON Yes Ye s
No
Enables/disables X-ON ow control
for the serial interface
USB Device
Class
Printer Printer
VCOM
Sets the USB device class
USB VCOM
Protocol
Auto Auto
DTR
X-ON
Sets the USB VCOM protocol (ow
control)
IPv4 Address
169.254.001.010
000.000.000.000 to
255.255.255.255
Sets the IPv4 network address
IPv4 Subnet
Mask
255.255.000.000
000.000.000.000 to
255.255.255.255
Sets the IPv4 subnet mask
IPv4 Gateway
000.000.000.000
000.000.000.000 to
255.255.255.255
Sets the IPv4 gateway
IPv4 DHCP On On
Off
Enables/disables IPv4 DHCP
Host Name CL-E321:
CL-321/300
Print Server
CL-E331:
CL-331/303
Print Server
Any length from 0 to
31 characters long
using single-byte let-
ters (uppercase and
lowercase), numbers,
and symbols
Name to assign to the device to
identify the printer
Port Number 9100 1024 - 65535 Print port number

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
