Citizen CL-E321 User Manual

59
——
Home menu Sub menu Default Congurable range Notes
After Print - 2 Paper Position 0.00 inch
0.00 mm
STD
0.00 to 2.00 inch
0.0 to 50.8 mm
Cut/Tear
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Adjusts the stop position.
This setting is dependent on the
Metric/Inch setting.
Each device has an initial stop
position as congured with the
settings previously described. This
setting sets a relative value from
these other settings.
Feed Key Action Feeds Media Repeat Last Set
Repeat Last One
Feeds Media
Changes the operation of the
FEED key
Repeat Last Set
Reprints a set of labels.
This setting is ignored when Ze-
bra®* emulation mode is selected.
Repeat Last One
Reprints the last page only.
Prints only 1 sheet/label from the
current number when using counts.
Feeds Media
Functions as the FEED key.
Disables reprinting.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
