- 175 -
fn=112: Function 112 Storing Raster Type Graphics Data to Print Buffer
GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn><a><bx><by><c><xL><xH><yL><yH> [d1…dk]
[Range] Parameter of GS ( L
11≤(pL+pH×256)≤65536(0≤pL≤255, 0≤pH≤255)
Parameter of GS 8 L
11≤(p1+p2×256)+p3×65536+p4×16777216≤4294967295
(0≤p1≤255, 0≤p2≤255, 0≤p3≤255, 0≤p4≤255)
Common parameter of GS ( L, GS 8 L
m=48
fn=112
a=48
bx=1, 2
by=1, 2
c=49(When monochrome color paper is specified), c=49, 50 (When 2-color paper is specified)
1≤(xL+xH×256)≤1024
When monochrome color paper is specified
1≤(yL+yH×256)≤1662(with by=1)
1≤(yL+yH×256)≤831(with by=2)
When 2-color paper is specified
1≤(yL+yH×256)≤831(with by=1)
1≤(yL+yH×256)≤415(with by=2)
0≤d≤255
k=(int((xL+xH×256)+7/8)×(yL+yH×256)
[Outline] [The specification which is common to the model]
• Stores raster type graphics data to print buffer as large as x times horizontally/y times vertically.
• xL, xH specifies the horizontal direction of raster graphics data to (xL + xH x 256).
• yL, yH specifies the vertical direction of raster graphics data to (yL + yH x 256).
• “c” specifies the color of print data.
c
Color of Print Data
49
1st color
50
2nd color
• 1st color denotes black (high energy) in the specified 2-color thermal paper.
• 2nd color denotes red (low energy) in the specified 2-color thermal paper.
[Caution] [The specification which is common to the model]
• In STANDARD MODE, each color can be defined only once.
