fn=102: Function 102 Sending setting of Bluetooth
GS ( E pL pH fn m
[Code] <1D>H<28>H<45>H<pL><pH><fn><a>
[Range] (pL+pHx256)=2(pL=2, pH=0)
Fn=102
CT-S281BD, CT-S801II/CT-S851II, CT-S601II/CT-S651II, CT-S251, CT-D151/ CT-E651
a=1, 2, 3, 4, 5, 6, 7, 8
[Outline] [The specification which is common to the model]
• Sends Bluetooth Communication information specified by “a”.
Hex
No. of Data
Header
37H
1
ID
66H
1
Bluetooth Communication
Information No.
31H to 38H 1
Separation Number
1FH
1
Set value 20H to 7FH
Depend on
number of Data
NULL
00H
1
• Bluetooth Communication Information No.
a
Sending
Data
Number of Set
value
Setting value
1
49(“1”)
0 to 16
PIN Code
2
50(“2”)
1 to 31
BT Device name
3
51(“3”)
1 to 31
(iAP) Manufacturer name
4
52(“4”)
1 to 31
(iAP)Model name
5
53(“5”)
1 to 63
(iAP)Protocol name
6
54(“6”)
10
(iAP)Bundle seed ID
7
55(“7”)
1 to 31
(iAP)Accessary name
8
56(“8”)
0 to 64
(iAP)Application ID
• Initial Value
a
Setting value
1
Bluetooth address Last 4 digits out of 12 digits (colon excluded)
2
Model name_xx (xx is last 2 digits of Bluetooth address)
CITIZEN SYSTEMS (CT-S281BD)
3
CITIZEN SYSTEMS
4
Model name (Example: CT-S801II)
5
com.citizen.protocol01
6
82KYFK9X2H
7
Model name_xx (xx is last 2 digits of Bluetooth address)
CT-S281BD or CSJ Accessory (CT-S281BD)
8
There is no character string
