- 382 -
GS ( z WaterMark,size,start,kc1,kc2,pass,feed,repeat
[Function] Specifying WaterMark Printing
[Code] <1D>H<28>H<7A>H<kind1～10><size1,2,3,4><start><kc1><kc2>
<pass1,2,3,4><feed1,2,3,4><repeat1,2,3,4>
[Range] kind1=87("W"), kind2=97("a"), kind3=116("t")、kind4=101("e"), kind5=114("r")
kind6=77("M"), kind7=97("a"), kind8=114("r"), kind9=107("k"), kind10=32(" ")
size=15 *size = size1+size2×256+size3×65536+size4×16777216
start＝0, 1
32≦kc1≦126, 32≦kc2≦126
48≦pass1,2,3,4≦57、65≦pass1,2,3,4≦70 ("0" to "9", "A" to"F")
*pass is after integer conversion hexadecimal character code of pass1,2,3,4,
determined by pass1＋pass2×256＋pass3×65536＋passl4×16777216.
48≦feed1,2,3,4≦57、65≦feed1,2,3,4≦70 ("0" to "9", "A" to "F")
*feed is after integer conversion hexadecimal character code of feed1,2,3,4,
determined by feed1+feed2×256+feed3×65536+feedl4×16777216.
48≦repeat1,2,3,4≦57、65≦repeat1,2,3,4≦70 ("0" to "9", "A" to "F")
*repeat is after integer conbersion hexadecimal character code of repeat1,2,3,4
determined by repeat1+repeat2×256+repeat3×65536+repeat4×16777216.
Data Size
Function
GS ( z
3 bytes
1DH 28H 7AH
Fixed
kind
10 bytes
“WaterMark”+20H(Space) 1 byte
Fixed
size 4 bytes
The number of bytes from start to the last.
Low byte -> High byte
(little endian)
size=15
start 1 byte
Watermark Printing starting: 01H Ending:
00H
0≦start≦1
kc1
1 byte
Keycode1
32
≦
kc1
≦
126
kc2
1 byte
Keycode2
32
≦
kc2
≦
126
pass 4 bytes
The number of blank Vertical dots until
watermark printing.
Specifies with a little endian in 4 digit of
hexadecimal number ASCII.
0000≦pass≦FFFF
feed 4 bytes
The number of blank Vertical dots during
watermark printing.
Specifies with a little endian in 4 digit of
hexadecimal number ASCII.
0000≦feed≦FFFF
repeat 4 bytes
Repeat count. Infinite at 0.
Specifies with a little endian in 4 digit of
hexadecimal number ASCII.
0000≦repeat≦FFFF
