46 NX501E/NZ501E
English
Owner’s Manual
PTY seek
1. Touch the [
] key.
2. Touch the [
] key (program type display) to
display the PTY Select screen.
3. Touch your desired PTY Preset key to select the
program type.
4. Touch a Seek key, the system seeks a PTY
broadcast moving up the frequencies.
• If no station with the selected PTY broadcast can be
received, the unit returns to the previous mode.
• The 32 types of PTY listed below can be selected.
PTY item
ENGLISH Contents
None None
News News
Affairs Current Affairs
Info Information
Sports Sport
Educate Education
Drama Drama
Culture Culture
Science Science
Varied Varied
Pop M Pop Music
Rock M Rock Music
Easy M Easy Listening Music
Light M Light Classical Music
Classics Serious Classical Music
Other M Other Music
Weather Weather
Finance Finance
Children Children’s Programs
Social Social Affairs
Religion Religion
Phone In Phone In
Travel Travel
Leisure Leisure
Jazz Jazz Music
Country Country Music
Nation M National Music
Oldies Oldies Music
Folk M Folk Music
Document Documentary
Test Test
Alarm Alarm
Emergency broadcast
If an emergency broadcast is received, all the function
mode operations are stopped. “Alarm” appears on the
screen and the emergency broadcast can be heard.
Volume setting of TA and emergency
broadcast (Alarm)
The volume for TA, Alarm and PTY interrupts can be
set during TA or Alarm.
• The factory default setting is “15”.
1. Use the [VOL +] and [VOL –] buttons to set the
volume to the desired level (00 to 40) during a TA or
Alarm.
• When the TA or Alarm ends, the volume returns to
the level before the interrupt.
To Next Page
