Clarion NX501E User Manual

64 NX501E/NZ501E
English
Owner’s Manual
Green
White
Red
Video In
Audio/L
Audio/R
Steering Wheel
Remote Control Terminal
Yellow
RearZone
Monitor
Yellow
Yellow
GPS
Antenna
External
Microphone
Connection
Radio Antenna
Gray
Black
Black
Black
Black
Video Out
4-Channel Amplifier
Subwoofer 1
Subwoofer 2
Line Out
Rear R
Line Out
Rear L
Line Out
Front R
Line Out
Front L
Purple
Gray
Black
White
Red
White
Red
White
Red
CAMERA
VISUAL IN
SWI
VIDEO OUT
DTV
2 ZONE OUT
Black
Red
White
Red
EX MIC
DVB-T Tuner (DTX501E)
iPod/iPhone
CCA-748 (sold separately)
Video Out
Rear Vision Camera
SUB WOOFER
AUX IN 2
7. Wire Connections
Note:
• Before installing, be sure to disconnect the negative cable of the car battery.
• In the optional devices, the RCA cables and the Connector cables are separately-sold items.
Refer to
page 66
NX501E

Clarion NX501E Specifications

General

MP3 playback	Yes
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Product color	Black
Audio output channels	4.0 channels
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.2 \
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
I/O ports	1x USB 2x A/V In
