6. Cautions on Wiring

1. Be sure to turn the power off before wiring.

2. Be particularly careful where you route the wires.

Keep them well away from the engine, and exhaust pipe, etc. Heat may

damage the wires.

3. If the fuse should blow, check to see if the wiring is correct.

If a fuse is blown, replace it with a new one of the same amperage rating as

the original (15A FUSE).

4. To replace the fuse, remove the old fuse on the back of the unit and insert

the new one. (Figure 8)

NOTE:

There are various types of fuse holder. Do not let the battery side touch other metal

parts.

Figure 8

Fuse (15A FUSE)

After the connection, ﬁx the cord by a clamp

or insulation tape for protection.

Fuse holder

CAUTION
