Clarke CA60 20D - Orbital Deck Disassembly;Assembly (Continued)

Service Manual-CA60 34 Scrub System REV (CA60 20B/24B) 69
Orbital deck Disassembly/Assembly （ Continues ）
6. Unscrew the bumper roller(H) screws. The weight block screws (I). The plate head deck screws(G).Remove it.
7. Unscrew the screws(K).
8. Turn over the orbital deck, Unscrew the screws(P). Take out the flex plate(Q)
H
G
I
K
I
P
Q
Q
Figure 7
H
H
