CleaverBrooks CBT User Manual

750-382
CBT
6-5
Control panel
6.3.2 — On/off
DESCRIPTION
PART NOQTYITEM
BRACKET, MOUNTING, ELECTRICAL008-00175-000
11
DIN MOUNTING RAIL, 9-3/4" LG.884-00195-000
1
2
BASE, CONTROLLER HW Q7800A1005/B
833-01278
1
3
CONTROLLER, PROGRAM, 50/60CYC
833-0156614
RELAY, PLUG-IN DPST 120V175-00306-000
15
CLAMP, END DIN MOUNTING TRACK832-01026
1
6
SWITCH, AIR PRESSURE, 0.1 +/- .03" WC
836-01598-0001
7
TERM, END COVER D-UT 2,5-10884-00263-00018
END CLAMP, CLIPFIX 35-5884-00249-00029
TERMINAL, ELECTRICAL, UT4884-00262-0001210
TERMINAL, ELECTRICAL, UT4884-00276-000111
FUSE BLOCK, CLASS CC, SINGLE POLE848-01491-000212
CONTROLLER, LWCO833-03547-000
1
13
CONTROLLER, LWCO & PUMP CONTROL833-03130-000
114
TRANSFORMER, ELECTRIC, IGNITION 120V832-00954115
BUSHING, SNAP, NYLON, 7/16" OD.
810-00060216
MACH. SCREW, #8-32 UNC x 1/2" PAN HD.860-00293
1417
TERMINAL MARKER, LARGE848-00251-0003418
LUG, FEMALE SPADE WIRING884-00287-000819
TERMINAL,ELEC,LUG,RING884-00232-000120
LUG, FORK WIRING #8 SCREW884-00058
1
21
LUG, 90 DEG FEMALE SPADE884-00072
4
22
LUG, FEMALE SPADE WIRING884-00286-000123
BLOWER FUSE 6A832-01881-000124
PANEL FUSE 5A832-01811-000
1
25
LABEL, CBT LIGHTS, ON/OFF & L-H-L
118-04778-000
1
26
SWITCH, TOGGLE, S.P.D.T. WO/CENTER OFF
836-08918-000127
LIGHT, NEON WHITE881-00136128
LIGHT, NEON GREEN881-00138
1
29
LIGHT, NEON RED881-00137
1
30
LIGHT, NEON AMBER881-00139131
RESET PUSH BUTTON836-01142-000132
PLUG, DOMED, .500" DIA HOLE848-00531233
MODULE, FLAME AMPLIFIER832-01072
1
34
2
9
12
25
12
24
9
8
11
10 12x
5
6
17
7
17
BLOWER
PANEL
14
13
H.W.A. OPTION
27
28
29
30
31
32
33
26
4
3
17
34
16
1
3x
17
17
16
15
17
