Commissioning
4-10
750-382
CBT
See also Chapter 5, Section E - Troubleshooting.
4.1.8 — Controller configuration
The CB Falcon controller should be factory configured for the specific CBT boiler model. Prior to starting the
boiler, verify that the factory default settings are correct for your application. Please refer to CB default settings,
Table 4-1, and make any changes at this time if needed.
The CB Falcon steam control parameter settings are organized into the following parameter groups:
• System ID & access
• Steam configuration
• Modulation configuration
• Pump configuration
• Statistics configuration
• Stack limit (future)
• Annunciation
• Burner control interlocks
• Burner control timings & rates
• Burner control ignition
• Burner control flame failure
• System configuration
• Fan configuration
• Lead lag configuration (future)
TABLE 4- 1. CB Falcon factory parameter settings - Model CBT-M
Parameter Group Parameter Name Access Min.
Range
Default Setting Max.
Range
Parameter Units Installation
Setting
Modbus
Register
(dec)
System ID & Access Burner name Service BOILER 1 20 chars 183
System ID & Access Installation data Service SERIAL NUMBER 20 chars 184
System ID & Access OEM identification Read Only CB Falcon 833-
03578
20 chars 185
System ID & Access Installer password Service 9220 20 chars 190
Steam Configuration Steam enable Service Enabled 208
Steam Configuration Steam demand
switch
Service B:STAT terminal 209
Steam Configuration Steam has priority
over LL
Service No 582
Steam Configuration Steam pressure
setpoint
User 0 10 142.5 psig 220
Steam Configuration Steam pressure on
hysteresis
Service 0 0 60 psig 221
Steam Configuration Steam pressure off
hysteresis
Service 0 6 60 psig 222
Steam Configuration Steam TOD pressure
setpoint
Service 0 psig 542
Steam Configuration Steam setpoint source Service Local 578
Steam Configuration Steam modulation
rate source
Service Local 580
Steam Configuration Steam 4mA steam
pressure
Service 0 0 psig 585
Steam Configuration Steam 20mA steam
pressure
Service 0 135 150 psig 586
