Full modulation boilers
Steam Configuration Steam modulation
sensor
Service C:Modulation from
Inlet S1 (J8-4)
sensor
210
Steam Configuration Steam P gain Service 25 216
Steam Configuration Steam I gain Service 25 217
Steam Configuration Steam D gain Service 0 218
Steam Configuration Steam hysteresis step
time
Service 0m 0s mmm ss 219
Modulation
Configuration
Maximum modulation
rate
Service 2000rp
m
Table 4-2 6500rpm RPM 193
Modulation
Configuration
Minimum modulation
rate
Service 800rpm Table 4-2 3000rpm RPM 195
Modulation
Configuration
Steam forced rate Service 1000rp
m
2000rpm 6500rpm RPM 199
Modulation
Configuration
Steam forced rate
time
Service 1m 0s 240m 0s mmm ss 200
Modulation
Configuration
Firing rate control User A:Automatic firing 204
Modulation
Configuration
Manual firing rate User 800rpm 2000rpm 6500rpm RPM 205
Modulation
Configuration
Analog input
hysteresis
Service .2 mA 543
Pump Configuration CH pump output Service A:No pump
assignment
272
Pump Configuration CH pump control Service A:Automatic pump
control
273
Pump Configuration CH pump start delay Service 0m 0s mmm ss 292
Pump Configuration CH pump overrun
time
Service 1m 0s mmm ss 274
Pump Configuration Boiler pump output Service C:Pump assigned to
terminal B
281
Pump Configuration Boiler pump control Service A:Automatic pump
control
282
Pump Configuration Boiler pump start
delay
Service 0m 0s mmm ss 293
Pump Configuration Boiler pump overrun
time
Service 1m 0s mmm ss 283
Pump Configuration Auxiliary 1 pump
output
Service A:No pump
assignment
284
Pump Configuration Auxiliary 1 pump
control
Service A:Automatic pump
control
285
Pump Configuration Auxiliary 1 pump
start delay
Service 0m 0s mmm ss 295
Pump Configuration Auxiliary 1 pump
overrun time
Service 0m 0s mmm ss 752
Pump Configuration System pump output Service D:Pump assigned to
terminal C
287
Pump Configuration System pump control Service A:Automatic pump
control
288
Pump Configuration System pump start
delay
Service 0m 0s mmm ss 294
Pump Configuration System pump overrun
time
Service 1m 0s mmm ss 289
Pump Configuration Auxiliary 2 pump
output
Service B:Pump assigned to
terminal A
755
Pump Configuration Auxiliary 2 pump
control
Service A:Automatic pump
control
756
TABLE 4- 1.
CB Falcon factory parameter settings - Model CBT-M (Continued)
Parameter Group Parameter Name Access Min.
Range
Default Setting Max.
Range
Parameter Units Installation
Setting
Modbus
Register
(dec)
