CleaverBrooks CBT User Manual

Parts
6-12
750-382
CBT
6.5 — Water Column
4
9
26
24
23
21
20
18
PROBE LENGTH CHART
PROBE USAGE
TERMINAL LENGTH
PUMP OFF C
8-1/4"
PUMP ON B
9-1/4"
LWCO A
10-1/2"
HIGH WATER ALARM D
6-3/4"
TSET YB DBTOCWLA
32
11
16
28
9
32
11
22
DESCRIPTIONPART NO
PART NO
QTY
QTY
ITEM
ALWCO PROBE HOLDER817-03984-00014
VALVE, BALL941-00055-00029
GAUGE, PRESSURE
850-00122-000111
SENSOR, MODULATING CONTROL817-04386-000116
PRESSURE CONTROL, OP LIMIT817-04093-000
1
18
PRESSURE CONTROL, HIGH LIMIT817-04092-000120
LWCO CONTROL AND CASTING817-03983-000
1
21
GUAGE GLASS VALVE SET825-00132-000
1
22
GLASS, TUBULAR, PYREX851-00199-000123
GAUGE GLASS PROTECTOR SET912-00085-000424
VALVE, BALL
941-01790-000
1
26
ROD ELECTRODE
067-00873-000128
VALVE, BALL
941-03093-000132
150# STEAM
817-03984-0001
941-00055-0002
850-00243-0001
817-04385-0001
817-04095-000
1
817-04094-0001
817-03983-000
1
825-00281-000
1
851-00199-0001
912-00085-0002
067-00873-000
1
941-01790-000
1
941-03093-0001
15# STEAM
LENGTH
7-1/4" *
8-1/4" *
10-1/2"
5-3/4" *
TSET YB DBT
! IMPORTANT !
* CUT PROBES TO LENGTH
10-30 HP 150#
20-30 HP 15#
10-15 HP 15#
PROBE P/N
873-00581-000
873-00580-000
873-00579-000
873-00582-000
067-00873-000
