750-382
CBT
6-11
Burner assembly
6.4.6 — 30 HP on/off
DESCRIPTION
PART NO
QTYITEM
PLATE ASSEMBLY, BURNER MOUNTING FLANGE, ON/OFF
059-00030-00011
GASKET, BURNER FLANGE380-01168-00012
DRY OVEN ASSEMBLY, ON/OFF BURNER, CBT 30HP279-00218-00013
GASKET, DRAWER ASSEMBLY380-00225-00014
DRAWER ASSEMBLY429-00168-0001
5
GASKET, ADAPTER PLATE TO BLOWER380-01037-000
1
6
BLOWER UNIT, G1G170, 115V894-04076-000
17
PLATE, ORIFICE, AIR, Q-SERIES, CBT 10HP 059-00021-000
1
8
HARDWARE KIT, CONTAINS: (6) CAPSCREW, HEX SPINLOCK HEAD 880-04453-000
1
9
CLAMP, LOOP
015-00206-000131
TUBING, COPPER 1/4" OD x .035" WALL x 3.75" LG.
939-00025-000132
BUSHING, NYLON ADAPTOR
222-00079-000110
HOSE, CLEAR VINYL 7-1/2" LG.
861-00259111
HOSE, CLEAR VINYL 15-1/2" LG.
861-00259112
SUB-BASE, CONTROLS ASSEMBLY, ON/OFF BURNER
140-00022-000113
ROPE, FIBERGLASS853-01105-000129
FILTER, AIR
380-00226-000130
13
10
12
POSITIVE
11
NEGATIVE
7 6
8
9
32
31
NEGATIVE
10
POSITIVE
5
25 27
4
3
26 28
2
29
1
30
