CleaverBrooks CBT User Manual

Parts
6-10
750-382
CBT
6.4.5 — 20-25 HP on/off
DESCRIPTIONPART NOQTYITEM
PLATE ASSEMBLY, BURNER MTG FLANGE
059-00097-00011
GASKET, BURNER FLANGE380-00901-00022
DRY OVEN ASSEMBLY
279-00224-000
1
3
GASKET, DRAWER ASSEMBLY380-00225-00014
DRAWER ASSEMBLY
429-00178-000
15
GASKET, ADAPTER PLATE TO BLOWER380-01037-000
1
6
BLOWER UNIT, G1G170, 115V894-04076-0001
7
PLATE, ORIFICE, AIR, ON-OFF BURNER
SEE TABLE18
HARDWARE KIT, CONTAINS: (6) CAPSCREW880-04453-000
1
9
BUSHING, NYLON ADAPTOR
222-00079-000
1
10
HOSE, CLEAR VINYL, 9-1/4" LG.
861-00259111
HOSE, CLEAR VINYL, 18-3/4" LG.
861-00259112
SUB-BASE, CONTROLS ASSEMBLY140-00022-000
1
13
LAGGING, BLOWER COVER107-00149-000
114
PIPING, GAS TRAIN185-03288-000115
BRACKET, GAS TRAIN008-00176-000116
U-BOLT841-01123-000
117
ROPE, FIBERGLASS853-00348-000
1
29
FILTER, AIR
380-00226-000
1
30
CLAMP, LOOP
015-00206-000131
TUBING, COPPER
939-00025-000132
NAMEPLATE, INSTALLATION - WARNING 118-03814-000
1
33
NAMEPLATE, UL GAS FIRED BOILER
118-00331-000
1
34
LABEL, CONTROL PANEL, CBT BOILERS118-04743-000135
NAMEPLATE, "CLEAVER-BROOKS" LOGO
118-00247-000136
NAMEPLATE, CBT LABEL SHEET118-00401-000
1
37
HARNESS, MOTOR POWER CORD832-02101-000139
13
10
12
POSITIVE
11
NEGATIVE
7
6
39
89
32 31
NEGATIVE
10
POSITIVE
5
4
3
2
29
1
30
37
HP ASSEMBLY NO. ITEM #8
20 829-00211-000 059-00023-000
25 829-00212-000 059-00024-000
