1 Specifications
1.1
Technical sheet
PERFORMANCE
Max. working height 14,90 m 48.89 ft
Max. work outreach 6,90 m 22.64 ft
Max. load on the basket 200 kg (USA) 441 lb. (USA)
Jib movement 90°
Turret rotation +/-178° (356° non-continuous)
Basket rotation NO
(P) Max. slope to stabilize 8° / 14%
(W) Max. ramp attack slope
16° / 29% (with jib closed)
30° / 58% (with jib lifted and
on engine side)
(X) Max. slope to travel 14° / 25%
Travel speed 0,4 - 1,9 km/h 0.25 - 1.18 mph
DIMENSIONS
(A) Basket height 1,10 m 3.61 ft
(B) Basket width 0,60/0,70 m 1.97/2.30 ft
Basket length 0,80/1,20/1,40 m 2.62/3.94/4.59 ft
(D) Total length 4,13 m 13.55 ft
(E) Length without basket 3,39 m 11.12 ft
(F) Height in driving position 1,98 m 6.50 ft
(G) Total width (without basket) 0,77 m 2.53 ft
(H) Clearance from the ground
in transport position
0,29 m 0.95 ft
Tracks (l x w x h) 1,21 x 0,18 x 0,36 m 3.97 x 0.59 ft x 1.18 ft
Tracks enlargement (*optional) 0,77/1,17 m 2.53/3.84 ft
(J) Max. longitudinal stabilization 2,70 m 8.86 ft
(K) Max. cross stabilization 2,70 m 8.86 ft
Outriggers plate Ø 0,18 m 0.59 ft
WEIGHT AND PRESSURES
Total weight (standard equipment) 1920 kg 4233 lb.
(R) Max. pressure on the foot
4,54 Kg/cm²
(44,46 N/cm²)
64.57 lb./in
2
(S) Max. pressure on the track
0,21 Kg/cm²
(2,03 N/cm²)
2.99 lb./in
2
(T) Max. pressure in travel
312 Kg/m²
(3,06 KN/m²)
1523 lb./ft
2
(U) Max. pressure in work
246 Kg/m²
(2,42 KN/m²)
1201 lb./ft
2
POWERS
Standard hydraulic feed
1) Honda GX390 benzina, 8.7 kW (11.7
HP), 3600 rpm
*Optional hydraulic feed
2) Honda iGX390 benzina, 8.7 kW (11.7
HP), 3600 rpm
3) Yanmar L100V diesel, 6.8 kW (9.1 HP),
3600 rpm
4) Kubota Z482-E4B diesel, 9.9 kW (13.3
HP), 3600 rpm
5) Electric engine 230 V - 2,2 Kw (EU) / 110
V - 2,2 Kw (UK) / 120 V - 1,6 Kw (USA)
6) Electric engine G0901306, 5.5 kW, 48 V,
