MAN.161 Rev.7 ENG - Use and maintenance manual S15 page
51
of
71
8.10
Safety rules during maintenance
THE NON-OBSERVANCE OF ONE OF THE FOLLOWING SAFETY
RULES CAN SERIOUSLY HBOOM PEOPLE OR CAUSE SEVERE
DAMAGES TO THINGS OR PARTS OF THE EQUIPMENT OR OF
THE MACHINE.
To ensure the safety of the machine the use of original spare parts
installed by C.M.C. or by authorized repair shops is compulsory:
in fact, some components can be calibrated only c/or C.M.C. or in au-
thorized workshops
.
It is forbidden to perform maintenance operations when the
MEWP moves: make sure that the parts to maintain are motionless
and do these operations with the motor of the chassis stalled, taking
the keys away from the panel;
Perform the maintenance operations in a sufficiently large space and
suited to the sizes of the truck: mark the area assigned for the mainte-
nance operations by suited enclosure or by a red/white band ribbon and
do not allow entrance to unauthorized staff.
Do not modify or remove safety devices.
Do not modify calibrated pieces.
During the washing operation, do not lead the water jet directly on the
electrical panels of the MEWP and do not use cleansing, aggressive
chemicals dangerous for the components of the MEWP (rubber parts,
painted parts, etc.).
It is forbidden to perform any intervention on parts of the MEWP,
such as welding, piercing, and so on, without prior written authori-
zation by C.M.C.
Wear appropriate protective clothes (gloves, goggles, etc.).
During maintenance operations, be careful not to damage the hydraulic
circuit and avoid impurities in the circuit.
Before any maintenance operation that involves the disassembly of hy-
draulic circuit parts, make sure that the system is not under pressure. In
order to avoid violent emissions of oil, move all the levers of the control
distributors, with the truck motor stalled and no component in move-
ment.
8.11
Maintenance of endothermic
engine
The standard supplied petrol engine has the following technical characteris-
tics:
o HONDA GX390 petrol engine, single cylinder OHV with horizontal
shaft, 4 strokes, cylinder inclined at 25 °, forced air cooling, cast iron
cylinders.
Data Value
Unit of
Cylinder capacity 389 cm
3
Net power at 3600 rpm 8.7 (11.7) kW (HP)
Maximum torque at 2500 rpm 26.5 N/m
Dry weight 69.89 lbs.
Dimensions (L x W x H) 1332 x 1509 x 1470 ft
Fuel consumption at 3600 rpm 3.5 l/h
Fuel tank capacity 6.1 l
Other supplied motor as optional* has the following technical characteris-
tics:
o HONDA iGX390 petrol engine, single cylinder OHV with horizontal
shaft, 4 strokes, cylinder inclined at 25 °, forced air cooling, cast iron
cylinders.
Data Value
Unit of
