MAN.161 Rev.7 ENG - Use and maintenance manual S15 page
52
of
71
Cylinder capacity 389 cm
3
Net power at 3600 rpm 8.7 (11.7) kW (HP)
Maximum torque at 2500 rpm 26,5 N/m
Dry weight 37,0 kg
Dimensions (L x W x H) 409 x 484 x 448 mm
Fuel consumption at 3600 rpm 3,5 l/h
Fuel tank capacity 6,1 l
o YANMAR L100
,
air-cooled diesel engine, vertical cylinder, 4 strokes.
Data Value
Unit of
Bore x Stroke
Ø 86 x 75
mm
Displacement 0.435 liter
Continuous Rated Output
(3000 - 3600 rpm)
5.7 - 6.2 kW
Maximum Rated Output
(3000 - 3600 rpm)
6.3 - 6.8 kW
Engine weight (dry) 53.5 kg
Dimensions (L x W x H) 412 x 472 x 494 mm
Fuel tank capacity 5.4 liter
8.12
Maintenance of 48 V electric
engine
(*op-
tional)
The 48 V electric engine with battery pack, provided as optional* in full lith-
ium version, has the following technical characteristics:
Battery Composition LiFePo4
Typical Capacity 160 [Ah]
Cells Configuration 15S1P
Rated Voltage 48 [V]
Maximum Voltage Fully Charge 54.8 [V]
Minimum Operative Voltage 42 [V]
Rated Discharge Current 30 [A]
Maximum Discharge Current 100 (electronically limited)
[A]
Rated Charge Current 30 A (0.3 C)
DoD 80 [%]
Cycle Battery Life
>2000 Ccle@80%DoD or
>3000 Cycle@70%DoD
Operative Temperature (during
charge)
-20/+60* [°C]
Operative temperature (during
discharge)
-20/+60 [°C]
Battery Weight 70 approximately [kg]
Maximum Output Power 4.8 [kW]
Rated Energy 4.32 [kWh]
*When charge is operated at less than 0°C the charge current is electronically lim-
ited at 10 A.
Voltage Input 100 - 240 Vac
Frequency Input 50 - 60 Hz
Maximum Output Voltage >=60 V
Maximum Current 22 A
PWM Frequency 1 kHz
International Protection IP20
Weight 2,2 Kg
Dimension (L*W*H) 180x310x100 mm
8.13
Consumables
Hydraulic oil:
