7 Hydraulic system
The MEWP hydraulic system is attached to the manual.
The pressure setting of the maximum valves must correspond to the follow-
ing values:
Data Value
Unit of
Turret workbench 220 (3191) bar (psi)
Filters workbench 230 (3336) bar (psi)
Outriggers workbench 190 (2755) bar (psi)
Travel workbench 190 (2755) bar (psi)
Levelling valve 120 (1740) bar (psi)
Turret rotation 90 (1305) bar (psi)
All the operations requiring the intervention on the components
of the machine, shall be carried out by authorized and trained
technical staff.
Non-authorized staff shall not replace any of the components. Many
components have been calibrated: a correct calibration of these
parts (possible only in C.M.C. or in authorized Services) is nec-
essary to ensure the safety of the machine.
