19
Except for the keyboard, all the other parts can be re-defined using the
【ASSIGN】button to send other data.
7.2 Registration BANK access
z You can save all the instrument settings to the registration BANK.
z Press the【MASTER】button to show the current registration bank# and name:
0 0 - V X M A S T E R
You can change the bank# then press [ENTER] to recall the settings from that
registration bank. To change the bank#, press either the <PAGE or PAGE>
button. When the bank# flashes, you can change it.
If the current settings are changed, when you recall settings from another
registration bank, there will be a message as below:
S a v e C u r r e n t ?
Y e s / N o
Press【No】 to recall from another registration bank without saving current
settings.
Press 【Yes】 to save current settings, and you can select the registration bank#
and rename the bank:
S a v e T o :
0 3 - U s e r 0 1
7.3 Selecting bank and voice
z Here the “bank” means tone bank. You can change the voice by selecting the bank#
and voice#.
z When you are playing the instrument, it will show the information as below:
P : 0 0 1 - G r a n d P
M S B : 0 0 0 L S B : 0 0 0
P: the voice # and name. The voice # range is 001-128, refer to appendix <GM
voice list>.
MSB & LSB: the BANK MSB & LSB#, range is 000-127.
To make changes, use the <PAGE and PAGE> button until the value flashes,
then change the value and press ENTER.
Everytime you change one of the above data, all three MIDI messages will be
sent.
7.4 Tanspose and octave
z You can shift the keyboard pitch in semi-notes by using the Transpose function.
z You can shift the keyboard pitch in octaves by using the Octave function.
z The default keyboard ranges of VX 5/6/7/8 are listed below:
