19 Specifications
z Keyboard
VX5: 49 keys(C1 - C5), velocity sensitive and aftertouch
VX6: 61 keys(C1 - C6), velocity sensitive and aftertouch
VX7: 76 keys(A-1 - C6), velocity sensitive and aftertouch
VX8: 88 keys(C-1 - C7), Graded Hammer Action Keyboard, velocity sensitive
and aftertouch
z Functions
Basic functions: USB MIDI, USB AUDIO, Octave shift, Transpose, Pitch bend
wheel, Modulation wheel, Ribbon control, Pedals, Breath control, Audio In, Audio
Out, Headphone out, MIDI IN, MIDI OUT
MIDI Data: Sequence control, MIDI clock, bank select, Program change, GM
System On, GS System on, XG System On, Control change, All Notes Off, etc.
Parameters: Transose, Octave, MIDI out ports and channels, Velocity curve,
Pitch bend, Breath control, Moulation, Brightness, Aftertouch, Aftertouch curve,
etc.
z Panel Controls and Indicators
Function buttons with light x 8, Function shortcut buttons with light x 8
Potentiometer knobs x 8, Encoder knobs x 9, Motorized faders x 9
Data dial x 1, Switch button with light x 1, Number buttons x 10,
Cursor/Inc/Dec/Confirm buttons x 6
Seq transport buttons x 6, U-CTRL button with light x 1
Transpose buttons with light x 2, Octave buttons with light x 2
Pads with light x 12
z Display
16 digs, two lines LCD display
z Input/Output Terminals
POWER ON/OFF switch x 1, POWER IN connector x 1
USB port x1, USB HUB port x 2
HEADPHONE jack 2, HP VOLUME knob x 1
LINE OUT jack x 2
LINE IN jack x 2, INPUT GAIN knob x 1
PEDAL jack x 2, BREATH Control jack x 1
MIDI OUT port x 4, MIDI IN port x 1
z Power Supply
AC Power Adaptor included
AC Power Adaptor requirement: 16V 2.6A DC
z Dimensions (W x D x H) and Weight
VX 5: 859 x 348 x 113mm, 9.62kg
VX 6: 1022 x 348 x 113mm, 11.30kg
VX 7: 1232 x 348 x 113mm, 13.38kg
VX 8: 1408 x 372 x 150mm, 26.94kg
* Specifications and appearance are subject to change without notice.
