23
8.2 Assigning keyboard and wheels
z Keyboard:
K e y b o a r d 1 - 1
P o r t : 1 C H : 0 0 →
You can set the MIDI port and channel to send data.
z Pitch Bend Wheel:
P i t c h B e n d 1 - 2
1 2 8 - P i t c h B e n d ← →
Set the CC #.
P i t c h B e n d 1 - 3
0 0 0 - 0 6 4 - 1 2 7 ← →
Set the value range.
P i t c h B e n d 1 - 4
P o r t : 1 C H : 0 0 ← →
Set the MIDI port and channel
z Modulation Wheel:
M o d u l a t i o n 1 - 5
C C : 0 0 1 - M o d u l a t ← →
Set the CC #.
M o d u l a t i o n 1 - 6
0 0 0 - 1 2 7 ← →
Set the value range.
M o d u l a t i o n 1 - 7
P o r t : 1 C H : 0 0 ←
Set the MIDI port and channel.
