29
8.8 Assigning encoder buttons
z Encoder knobs:
E n c o d e r - 1 7 - 1
0 1 0 - P a n →
Select one from the 9 encoder knobs.
Set the CC #.
E n c o d e r - 1 7 - 2
0 0 0 - 1 2 7 ← →
Set the value range.
E n c o d e r - 1 7 - 3
P o r t : 1 C H : 0 0 ←
Set the MIDI port and channel.
If there is no channel data in the MIDI message, you cannot set the channel #.
8.9 Assigning faders
z Faders(Sliders):
S l i d e r - 1 8 - 1
0 0 7 - V o l u m e →
Select one from the 9 faders (sliders).
Set the CC #.
E n c o d e r - 1 8 - 2
0 0 0 - 1 2 7 ← →
Set the value range.
E n c o d e r - 1 8 - 3
P o r t : 1 C H : 0 0 ←
Set the MIDI port and channel.
