Page #58 background imageLoading...
Page #58 background image
Settings
44 Chapter 2: Operation 98-171832-A
DSC
Parameter Description
MMSI The MMSI of the radio. 9 digit numerical (Default: Not set,
password protected if set). See the installation manual for a step-
by-step description.
GROUPS Shows DSC groups. You can add, edit and delete groups here. Each
entry in a group consists of MMSI, name and enabled/disabled.
POSITION
•SOURCE: GNSS (default) or MANUAL
GNSS INPUT PORT:
AUTOMATIC: Automatically select position source with
the best quality. In Automatic mode the position device
transmitting sentences with the best quality indicator will be
used as position source.
NMEA: NMEA 1 position input
NMEA HS: NMEA 2 position input
LWE1: Specific LWE position input (see LWE Talkers below)
LWE2: Specific LWE position input (see LWE Talkers below)
LWE3: Specific LWE position input (see LWE Talkers below)
INM-C: SAILOR Inmarsat C position input
CURRENT AUTOMATIC GNSS INPUT (if GNSS INPUT PORT is
AUTOMATIC): NMEA, NMEA HS, LWE1, LWE2, LWE3 or INM-
C (read only)
CURRENT POSITION (editable if source is MANUAL):
•LATITUDE
•LONGITUDE
•UTC TIME
LWE1: AUTO or specific Talker ID
LWE2: AUTO or specific Talker ID
LWE3: AUTO or specific Talker ID
