COBHAM SAILOR 7224 User Manual

SAILOR 7224 Control Unit
98-171832-A Appendix A: Specifications 61
SAILOR 7224 Control Unit
Intermodulation response 76 dB
Co-channel rejection Better than -10 dB
Adjacent channel
selectivity
80 dB
Blocking response Better than 100 dBV @ ±1 MHz
Receiver @ DSC
Sensitivity -117 dBm
Adjacent channel
selectivity
Below 80 dB
Intermodulation response Better than 70 dBV
Blocking response Better than 100 dBV
Item Specification
Item Specification
Weight 1.0 kg (2.2 lbs)
Dimensions Height: Outer dimension 107 mm, hole height for flush
mount 89 mm
Width: Outer dimension 241 mm, hole width for flush
mount 227 mm
Depth: Outer dimension from front of knobs 104 mm,
depth for flush mount 94 mm
Operating temperature -15°C to 55°C (5°F to 131°F)
Storage temperature -25°C to 70°C (-13°F to 158°F)
