SAILOR 7224 Control Unit
62 Appendix A: Specifications 98-171832-A
Ingress Protection IP54 when flush-mounted (Estimated, only front
exposed)
IP20 for other installation (whole unit exposed)
Power supply +24 V DC nom. (-10% / +30%)
Power consumption 10 W @ 24 VDC standby
33 W @ 24 VDC max
Heat dissipation 8.5 to 15 W
Display 5.5” TFT with capacitive multi touch – 350 cd/m2. (e.g.
800x600, 1024x768) – 40k hours to half brightness
Speaker Internal speaker – Max audio output power: 6W (internal
LS @ 5 kHz deviation/1kHz)
LAN 2 LAN ports supporting RSTP and 10/100 Mbit
1 LAN port not supporting RSTP
USB USB 2.0
CTRL Port Supporting up to four SAILOR 6204
ACC Port Supporting Handset & Hand Microphone. NMEA for
GNSS and AIS
AUX Port Support for VDR, Alarm I/O, GNSS, AUX OC and Ext.
Speaker. Max audio output power: 6W (external LS @ 5
kHz deviation/1kHz)
OPT Port Supporting NMEA RX and TX for BAM support
Item Specification
