98-171832-A 59
Appendix A
Specifications A
SAILOR 7226 VHF Transceiver Unit
Item Specification
Weight 1.5 kg (3.3 lbs)
Dimensions Height: Outer dimension 161 mm
Width: Outer dimension 306 mm
Depth: Outer dimension 51 mm
Operating temperature -15°C to 55°C (5°F to 131°F)
Storage temperature -25°C to 70°C (-13°F to 158°F)
Ingress Protection IP20
Power supply 24 VDC +30%/-10%
Power consumption
(typical)
Rx operative: 8 W
Tx 25 W operative: 65 W
Tx 1 W operative: 18 W
Heat dissipation (typical) Rx operative: 8 W
Tx 25 W operative: 40 W
Tx 1 W operative: 17 W
RX/TX ant. Input/output 50 ohm @ TX voice/TX DSC & RX voice
DSC ant. Input 50 ohm @ RX DSC
LAN 2 LAN ports Category 6 STP
