COBHAM SAILOR 7224 User Manual

SAILOR 7226 VHF Transceiver Unit
60 Appendix A: Specifications 98-171832-A
Item Specification
Frequency range Voice: 156.000 MHz — 164.000 MHz
DSC: 156.525 MHz
Channel spacing 25 kHz, all international maritime channels
Number of P channels The radio may be programmed with up to 100 private
channels in all channel modes.
Modulation 16K0G3E, 16KOG2B (DSC)
Transmitter
RF output power High: 25 W +0 dB / - 1.5 dB
Low: 1W +0dB / - 1.5dB
Frequency error +/- 3ppm
Adjacent channel power Below 80 dB
Conducted spurious
emission
Below 0.25 mW
Distortion Below 3%
S/N ratio Better than 46 dB
Receiver @ voice
Sensitivity < -119 dBm typically @ 20 dB SINAD CCITT weighted
LF power Built-in loudspeaker: 6 W (at 5 kHz dev./1 kHz tone)
External loudspeaker: 6 W / 8 Ohm
Distortion Below 5%
Spurious emissions Below 2 nW
Spurious response
rejection
80 dB
