VHF radio with DSC Class A
2 Chapter 1: Introduction 98-171832-A
Ethernet interface connects the Control Unit with the Transceiver Unit, and
enables the VHF radio to be connected to other units in a local network. Instead
of the touch screen on the Control Unit, you can also connect a PC or other
device with a browser for setup and control via the web interface.
For a list of accessories available for the VHF radio see Accessories available on
page 4 and check with your nearest distributor.
Controls on the front plate of the Control Unit
1. Loudspeaker.
2. Large 5.5” TFT display with capacitive multi touch.
3. Volume control, on/off and Squelch control.
4. Distress button for sending a Distress alert.
5. Channel selector and dim knob with push-function to switch between
channel selection and dimming.
Figure 1: Controls on the front plate of the Control Unit
