Cocoon Cooltech - Refrigeration System

1.1.1. Refrigeration system
6
Ventilator radiator
7
Ventilator electronics
8
Emergency button
16
Control cable (peltier power supply) applicator 2
17
Control cable (peltier power supply) applicator 1
18
Buzzer
19
Backlight TFT
20
Communication cable + power supply 24V TFT
21
Internal temperature sensor
