Applicators power supplys
The expected value should be about 11V, but if it is 0V, check the source control cable, if it is
connected properly.
Adjustable power supply control connection
Power supply terminal
Cable colour
RC
White
PV
Red
V-
Black
If the connection is correct, check also the same cable if is properly connected to Main board, as
follows: power supply for applicator 1 to connector 17 and power supply for applicator 2 to connector
16.
