Applicator type
Resistance value
Straight
0 R
Thight
Curved
Oval
7,68Kohm
Tiny
4,22Kohm
Double
6,04Kohm
In case of having intermittent values, resolder or replace the resistor and recheck if the values are
stable.
Measure the resistance value
between marked pins (4 and 5) of
the lower connector of the
applicator
With 2 wrenches (size 10) remove 1
of the screws to release the shaft
and locking handle
Remove the 2 screws to separate the
2 covers
