ComAp IM-NT User Manual

InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
114
12.2.2.10 Setpoint: NominBusLImp
Group
Basic Settings
Range [units]
1 .. 32000 [kW]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used for adjusting the maximal allowed power transferred
from the busL to busR. It is used as the 100% for the IDMT overload
protection (BusL2PovrldProt) as well as for some regulation loops.
NOTE:
The actual setpoint units and range depend on setting of the Power format in
GenConfig.
12.2.2.11 Setpoint: BusLeftCTprim
Group
Basic Settings
Range [units]
1 .. 15000 [A]
Related FW
3.0
Description
Nominal current of the primary side of the busL current transformers. The
secondary side is adjusted by setpoint BusLeftCTsec.
12.2.2.12 Setpoint: BusLeftCTsec
Group
Basic settings
Range [units]
/5A, /1A [-]
Related FW
3.0
Description
Nominal current of the secondary side of the busL current transformers. The
primary side is adjusted by setpoint BusLeftCTprim.
NOTE:
The CT secondary nominal current is adjustable only in IM-NTC. The IM-NT
has the CT secondary nominal current adjusted fixedly to 5A regardless of
this setpoint.
