ComAp InteliDrive Lite

ID-FLX Lite & Telecom Global Guide
143
Setpoint group Engine protection Related FW 2.5.0
Range [units] 0 .. 10000 [U16]
Default value 10 -
Step 1
Comm object 9272 Related applications
Description
Shutdown limit level for AIN4.
AIN4 Level 2
6 back to List of setpoints
Setpoint group Engine protection Related FW 2.5.0
Range [units] 0 .. 3600 [s]
Default value 10 -
Step 1
Comm object 9273 Related applications
Description
Delay for Wrn/Sd AIN4 alarm.
AIN4 Del
6 back to List of setpoints
Setpoint group Engine protection Related FW 2.5.0
Range [units] NORMAL, CLASS C [-]
Default value NORMAL -
Step -
Comm object 13372 Related applications
Description
NORMAL
Protection behaves according to the standard configuration of Wrn/Sd alarm in
LiteEdit AINx configuration screen. Default state.
CLASSC
The protection is type “Running only” and does not depend on Running only tick
in LiteEdit AINx Alarm properties configuration window. Protection (Class C) is
working after AINx Del or sooner when appropriate value increases over AINx
Wrn limit +3 seconds – after engine start. Warning/ShutdDown protection is
activated with fix delay 0.5s.
Note: Class C protection is working and corresponding setpoints are visible only when corresponding
AIN is configured in Modify->Alarm properties-> Direction-> Window prot.
AIN4 Eval
6 back to List of setpoints
