ID-FLX Lite & Telecom Global Guide
63
LAO Function
LoadLimitAOut Analog output of Load Limitation PI control loop.
Functions 1 and 2 setpoints
Load limit Values
Load Input
ECU: RPM, Load,
CU: AI1-AI9,
AIO: AI1-AI4
Load Bias 0 - 10000 [- ]
LoadRequest 1 ±10000 [- ]
LoadRequest 2 ±10000 [- ]
LoadReq Ramp 1 - 10000 [- ]
LoadUpLimit 0 - 10000 [- ]
LoadDnLimit 0 - 10000 [- ]
Load Gain 0.0 ±200.0%
Load Integral 0.0 % - 100.0 %
Load CMP Input
ECU: RPM, Load,
CU: AI1-AI9,
AIO: AI1-AI4
Load CMP Off ±10000 [- ]
Load CMP On ±10000 [- ]
Note: For more information see Setpoints on page 91.
Functions 1 and 2 examples
General PI control loop
Engine Load limitation with analog output
General comparator
Engine Load limitation with On/Off output
Speed switch
General PI control loop
Purpose: PI control of any value.
Description: PI detects the difference between actual and requested value and changes the output to keep the
controlled value on the limit. Can be used PI in function 1 or 3
Function requires plug-in module with Analog output.
