ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
183
Setpoint group Bus Right Settings Related FW 2.0.0
Range [units]
50 .. Bus Right Overvoltage (page 182) [%]
Default value 60 % Alternative config YES
Step
1 % of Nominal Voltage Ph-Ph (page 177)
Comm object 9687 Related applications MCB, MGCB, BTB
Description
Threshold for Bus Right undervoltage. All three phases are checked. Minimum voltage out of three phases is
used.
Bus Right Undervoltage
6 back to List of setpoints
Setpoint group Bus Right Settings Related FW 2.0.0
Range [units] 0,0 .. 600,0 [s]
Default value 2,0 s Alternative config YES
Step 0,1 s
Comm object 9103 Related applications MCB, MGCB, BTB
Description
Delay for Bus Right Undervoltage (page 183) and Bus Right Overvoltage (page 182) protection.
Bus Right < > Voltage Delay
6 back to List of setpoints
Setpoint group Bus Right Settings Related FW 2.0.0
Range [units]
1 .. 150 [%] of Nominal Voltage Ph-Ph (page 177)
Default value 10 % Alternative config NO
Step
1 % of Nominal Voltage Ph-Ph (page 177)
Comm object 8288 Related applications MCB, MGCB, BTB
Description
Threshold for Bus Right voltage unbalance.
Bus Right Voltage Unbalance
6 back to List of setpoints
Setpoint group Bus Right Settings Related FW 2.0.0
Range [units] 0,0 .. 60,0 [s]
Default value 2,0 s Alternative config NO
Step 0,1 s
Comm object 8289 Related applications MCB, MGCB, BTB
Description
Delay for Bus Right Voltage Unbalance (page 183) protection.
Bus Right Voltage Unbalance Delay
6 back to List of setpoints
