Page #177 background image
InteliMains 210 Global Guide
177
3x CT (Current Transformer)
Note: To lock this setpoint against editing you also have to lock setpoint Connection Type 1 (page 295),
Connection type 2 (page 297) and Connection type 3 (page 299).
6 back to List of setpoints
Setpoint group Basic settings Related FW 2.0.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 8277 Related applications MCB, MGCB, BTB
Description
Nominal voltage (phase to neutral).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-N 1 (page
294), Nominal Voltage Ph-N 2 (page 296) and Nominal Voltage Ph-N 3 (page 298).
Nominal Voltage Ph-N
6 back to List of setpoints
Setpoint group Basic settings Related FW 2.0.0
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 11657 Related applications MCB, MGCB, BTB
Description
Nominal system voltage (phase to phase).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-Ph 1 (page
295), Nominal Voltage Ph-Ph 2 (page 297) and Nominal Voltage Ph-Ph 3 (page 299).
Nominal Voltage Ph-Ph
6 back to List of setpoints
Setpoint group Basic settings Related FW 2.0.0
Range [units] 0,1 .. 500,0 [V/V]
Default value 1,0 V/V Alternative config NO
Step 0,1 V/V
Comm object 9579 Related applications MCB, MGCB, BTB
Description
Bus voltage potential transformers ratio. If no PTs are used, adjust the setpoint to 1.
Bus VT Ratio
6 back to List of setpoints
