InteliMains 210 Global Guide
197
Setpoint group Power Management Related FW 2.0.0
Range [units]
#Starting Rel Load Reserve 2 (page 196) .. 110 [%]
Default value 80 % Alternative config NO
Step 1 %
Comm object 10653 Related applications MCB, MGCB
Description
This setpoint is used to adjust the load reserve for stop of next gen-set in relative mode. i.e. #Power
Management Mode (page 192) = REL.
IMPORTANT: Logical binary input LOAD RES 2 ACTIVE (PAGE 430) has to be activated,
otherwise setpoints of Load Reserve Set 1 are used.
Note: See Power management (page 78) chapter for more information.
#Stopping Rel Load Reserve 2
6 back to List of setpoints
Subgroup: Minimal Running Power
Setpoint group Power Management Related FW 2.0.0
Range [units] 0 .. 65 000 [kW]
Default value 210 kw Alternative config NO
Step 1 kW
Comm object 9584 Related applications MCB, MGCB
Description
This setpoint is used to adjust certain minimum value of the sum of nominal power of all running gen-sets. If
the function is active (by logical binary input Min Run Power Active (page 430)), then the gen-sets would not
be stopped, although the reserve for stop is fulfilled, if the total remaining nominal power drops below this
minimal value.
Note: Logical binary input Min Run Power Active (page 430)) needs to be activated on all gen-sets in the
same time.
#Min Run Power
6 back to List of setpoints
