InteliMains 210 Global Guide
205
Setpoint group Synchronisation Related FW 2.0.0
Range [units] 0,0 .. 100,0 [%]
Default value 10,0 % Alternative config NO
Step 0,1 %
Comm object 8650 Related applications MCB, MGCB, BTB
Description
This setpoint adjusts maximum difference between Bus Right and Bus Left voltage in respective phases for
synchronization.
Voltage Window
6 back to List of setpoints
Setpoint group Synchronisation Related FW 2.0.0
Range [units] 0 .. 90 [°]
Default value 10 ° Alternative config NO
Step 1 °
Comm object 8652 Related applications MCB, MGCB, BTB
Description
This setpoint adjusts the maximum absolute value of difference between actual phase angle between the
Bus Right and Bus Left voltages for synchronization.
Phase Window
6 back to List of setpoints
Setpoint group Synchronisation Related FW 2.0.0
Range [units] 0,0 .. 25,0 [s]
Default value 0,3 s Alternative config NO
Step 0,1 s
Comm object 8653 Related applications MCB, MGCB, BTB
Description
The period of time that the phase angle difference must be within Phase Window (page 205) and voltage
difference within Voltage Window (page 205) before the breaker is closed.
Dwell Time
6 back to List of setpoints
Setpoint group Synchronisation Related FW 2.0.0
Range [units] -0,50 .. 0,50 [Hz]
Default value -0,25 Hz Alternative config NO
Step 0,01 Hz
Comm object 14798 Related applications MCB, MGCB, BTB
Description
Slip frequency for slip synchronization (Synchronization Type (page 204) = Slip Synchro).
Slip Frequency
6 back to List of setpoints
