CombiLift C7700 - Page 69

C4-C5XL MK3 O&S
5-14
C4000MK3-OM-EN-11
6 PORT STEERING SOLENOID
87A
RELAY 9
30
86
85
87
BN BN
87A
RELAY LV
30
86
85
87
SEAT
SWITCH
R
GY
F12
7.5
SEATBELT
SWITCH
GY
LOCK VALVE SOLENOID
LOCK VALVE SOLENOID
LOCK VALVE SOLENOID
87A
RELAY 32
30
86
85
87
R
F14
10
AUXILIARY 6-PORT SOLENOID
58
54
GY
YR
BUTTON
On Top Of
LEVER
Section: 3 of 3Model: C3000 - C5000 & C5000XL
COMBILIFT LTD
Drawn By : David Murray
Title: GM LPG Electric Circuit (PLC)
Revision Date:22/05/15
58 54
30
