11
PIN ID J2 J3
Description To NIBP board To ECG interface panel
Working voltage 6.6V,5V,3.3V 5V
Module Function Measure ECG parameter
3.2.3 7 Parameter NIBP Module
The 7 parameter NIBP board is a parameter measurement components, it provides the following functions:
1. NIBP measurement;
2. SpO2 installation place;
3. IBP installation place;
4. Data exchange with the main board through the serial ports.
PIN ID
J1 J2 J5 J8 J9 J10 J11 J12 J15
