7.9 Removing the 7 Parameter NIBP Board
1. Remove the Battery as described above;
2. Separate the front and rear housing as described above;
3. Unplug the cables that connect to the 7 Parameter NIBP Board;
4. Unscrew four PM3×6mm screws to remove the 7 Parameter NIBP Board.
7.10 Removing Main Board
1. Remove the Battery as described above;
2. Separate the front and rear housing as described above;
3. Unplug the cables that connect to the Main Board;
4. Unscrew the four PM3×6mm screws on main board to remove the Main Board.
