Comen STAR8000 - Removing the Spo Module Assembly

40
7.11 Removing the SpO
2
Module Assembly
1. Remove the Battery as described above;
2. Separate the front and rear housing as described above;
3. Remove the 7 Parameter NIBP module as described above;
4. Remove the SpO2 module shield case, unscrews 2 screws on the back of the 7 parameter NIBP module,
you can take out the SpO2 module;
