Comen STAR8000 - Power Supply Module

12
Descripti
on
NIBP
pump
socket
NIBP
valves
socket
To
SpO2
interfa
ce
panel
IBP
socket
IBP
socket
To
IBP
interfac
e panel
7Paramete
r
communic
ation
socket
To
ECG
board
CAS
NIBP
socket
Working
voltage
12V 12V 3.3V 12V,5
V
5V 5V 12V,5V 6.6V,
5V,3.
3V
12V
Module
Function
Measure NIBP, SpO2, IBP, parameter
3.2.4 Power Supply Module
The power module is located at the back of the patient monitor. The main part of the power module is the
power board, which contains charging & power management , distributed different DC power to main
board ,7-parameter board, USB port, speaker and battery charging.
The AC power module transforms the input power into DC and then forwards them to each component of the
patient monitor. The input power comes from AC source. The patient monitor will run power from the AC
source whenever an AC source is available. If the AC source becomes unavailable, the patient monitor will
automatically switch to the battery power. This does not affect the monitor’s operating status.
