4. Unscrew the 7 screws to separate the LCD carefully from the front panel of the monitor show as

above;

5. Unscrew the 4 screws on top and bottom of LCD frame to separate the LCD carefully from the LCD

frame, as show below;

7.8 Removing the Alarm LED Board

1. Remove the Battery as described above;

2. Separate the front and rear housing as described above;

3. Disconnect the cable that connects to the Alarm LED Board, and then unscrew the two PA3×8mm

screws to remove the Alarm LED Board;
