Chapter 6 Performance Verification
6.1 IBP Test
6.1.1 BP \Performance Test
Tool required：MX960（medex）
Follow this procedure to perform the test.
1. Connect the patient simulator to IBP1 socket..
2. Click the IBP baseline on the screen, select “CH press set up”, set “ART” as CH1(arterial
pressure).Enter “SURVEY set up” menu, select IBP（1,2）setup select “IBP PRESSURE ZERO”, select
“CH1 ZERO”. Follow up the next step after screen display “IBP CH1 zero success”.
3. Press MX960 keypad continuously.
4. The IBP value show 100±1mmHg
5. Repeat the steps above for all the IBP channels.
6.1.2 IBP Pressure Calibration
1. Connect the patient simulator to IBP1 socket.
2. Click the IBP baseline on the screen, select “CH press set up”, set “ART” as CH1(arterial pressure).
3. Enter “SURVEY set up” menu, select IBP(1, 2)setup, select “IBP PRESSURE ZERO”, select “CH1
ZERO”, and set the CH1 pressure value as 100.
4. Press MX960 keypad straightly then click Channel 1Calibration.
5. The IBP value on the display will be “100” means the IBP calibration success, otherwise repeat below
operation.
6. Repeat the steps above for all the IBP channels.
6.2 NIBP Test
6.2.1 NIBP Leakage Test
Tools required:
