CommScope Era CAP M 9 - Notch-Filter Connectors; CAP M Hardware Options; Single Mounting Bracket

M0201AJB Era
™
Medium Power Carrier Access Point Installation Guide
© October 2018 CommScope, Inc. Page 7
CAP M Overview
Notch-Filter Connectors
TheCAPM7E/80-85/17E/19hastwoNotch-Filterconnectorsthatarereservedforfutureuse.The
connectors,whichareclosedbyajumper,haveaprotectivecover.Donotremovetheprotectivecoveror
interferewiththejumper.
Figure 3. Notch-Filter Connector on the CAP M 7E/80-85/17E/19
CAP M Hardware Options
ThefollowingsectionsdescribehardwareoptionsfortheCAPM.
Single Mounting Bracket
TheSingleMountingBracket(CommScopePN7821954-xx)providesthemountingbracketsrequiredto
mountanCAP
Mtoawallorothervertical,flatsurface.See"MountaCAPMUsingaSingleMountingBracket”
onpage25.
Protecve cover over the
Notch-Filter connectors
Notch-Filter connectors
closed with a jumper
